Shale Shaker Screen

Shale Shaker Screen

Description

Model	Mesh size	Dimension	Be applicable to	Weight
GMP-1	16-325	903×1155mm	SWACO BEM-3	5.6 kg
GMP-2	16-325	1212×1141mm	SWACO ALS-11	9 kg
GMP-3 (PWP)	16-325	697×1050mm	DERRICR FLC500 Series	6 kg
GMP-4 (PWP)	16-325	697×1053mm	DERRICK FLC2000	4.2 kg
GMP-5	16-325	697×846mm	DERRICK FLC313M	4 kg
GMP-6 (PWP)	16-325	915×1150mm	BRANDT LCM-ZD	8.6 kg
GMP-7 (PWP)	16-325	720×1220mm	KEMTRON KTL48 Series	5.6 kg
GMP-8 (PWP)	16-250	700×1165mm	华油一机厂 S250	4.6 kg
GMP-9	16-250	1186×1280mm	华油一机厂 2X60	9.2 kg

GMB-1(PMD)	80-210	635×1253mm	BRANDT BL-50
GMB-2(PMD)	80-210	697×1050mm	DERRICR FLC 500 Series
GMB-3(PMD)	80-210	697×1053mm	DERRICR FLC2000
GMB-4(PMD)	80-210	915×1150mm	BRANDT LCM-ZD

GMK-1	16-325	585×1165mm	SWACO MON900SE
GMK-2	16-325	635×1253mm	BRANDT BL-50
GMK-3	16-325	913×650mm	BRANDT VSM-300
GMK-4	16-325	720×1220mm	KEMTRON KTL48 Series
GMK-5	16-325	712×1181mm	SF300

GMF-1	20-150	600×1040mm	华油一机厂 NCS-300*2型
GMF-2	20-150	700×1165mm	华油一机厂S250系列
GMF-3	120-210	1400×460mm	华油一机厂ZCN系列
GMF-4	120-210	1000×1150mm	华油一机厂NS-115/2
GMF-5	20-80	927×914mm	JSS (U.S.A)
GMF-6	20-80	1219×1524mm	SSS (U.S.A)
