WIKA TW10 Thermowell with flange DN 1-1/2″ Bore 6.6mm PN 150lbs Length 400mm

● The TW10 series of thermowells with flange connection are suitable for use with numerous electrical and mechanical thermometers from WIKA.

● Heavy-duty design

● Coating for corrosive or abrasive process loads

● Possible thermowell forms: tapered, straight, stepped

● SKU: RWHD120U1Z

Connection to thermometer	■ ½ NPT female thread ■ G ½ female thread ■ M20 x 1.5
Bore size B	■ 6.2 mm [0.244 in] ■ 6.6 mm [0.260 in] ■ 7.0 mm [0.276 in] ■ 8.2 mm [0.323 in] ■ 8.5 mm [0.355 in] ■ 9.0 mm [0.354 in] ■ 9.8 mm [0.385 in] ■ 10.2 mm [0.402 in] ■ 12.2 mm [0.480 in]
Insertion length U	13 … 1,575 mm [0.5 … 62 in]
Connection length H	■ 57 mm [2.25 in] ■ 83 mm [3.25 in]
