Optical Data |
|
|---|---|
| Range | 60,000 mm |
| Smallest Recognizable Part | 50 µm |
| Switching Hysteresis | < 15 % |
| Light Source | Laser (red) |
| Service Life (T = +25 °C) | 100,000 h |
| Laser Class (EN 60825-1) | 2 |
| Max. Ambient Light | 10,000 Lux |
| Opening Angle | 12 ° |
Electrical Data |
|
|---|---|
| Sensor Type | Receiver |
| Supply Voltage | 10 … 30 V DC |
| Current Consumption (Ub = 24 V) | < 15 mA |
| Switching Frequency | 5 kHz |
| Response Time | 100 µs |
| Temperature Drift | < 10 % |
| Temperature Range | -25 … 60 °C |
| Switching Output Voltage Drop | < 2.5 V |
| Switching Output/Switching Current | 200 mA |
| Short Circuit Protection | yes |
| Reverse Polarity Protection | yes |
| Overload Protection | yes |
| Teach Mode | NT, MT |
| Protection Class | III |
Mechanical Data |
|
|---|---|
| Setting Method | Teach-In |
| Housing Material | Stainless steel, V2A (1.4305 / 303) |
| Full Encapsulation | yes |
| Degree of Protection | IP67 |
| Connection | M12 × 1; 4-pin |
| Weight | 74 g |
Output |
|
|---|---|
| Contamination Output | yes |
| PNP NC | yes |
Adjustable parameters |
|
|---|---|
| Circuit | NC NC/NO NO |
