Range of product: Telemecanique Safety switches XCS
Product or component type: Coded magnetic switch
Component name: XCSDMR
Design: Cylindrical
Size: Ø 30 x 38.5 mm
Contacts type and composition: 2 NC
Contact operation: Staggered
Material: Plastic
Electrical connection: Pre-cabled
Cable composition: 4 x 0.25 mm²
Approach directions: 1 direction
[Ue] rated operational voltage: 24 V DC
[Ie] rated operational current: 100 MILLIAMPERE
Contacts material: Rhodium
Switching capacity in mA: 0.1…100 mA
Insulation resistance: 1000 MOhm
Switching frequency: 150 Hz
Safety level: Can reach category 4 with the appropriate monitoring system and correctly wired conforming to ISO 13849-1, can reach PL = e with the appropriate monitoring system and correctly wired conforming to ISO 13849-1, can reach SIL 3 with the appropriate monitoring system and correctly wired conforming to IEC 61508
Safety reliability data: B10d = 50000000 value given for a life time of 20 years limited by mechanical or contact wear
Enclosure material: Thermoplastic PBT
Cable material: PVC
