| Connection type head A | Female connector, M8, 4-pin, straight, A-coded | ||||||||
| Connection type head B | Flying leads | ||||||||
| Locking plug connector | Screw connection | ||||||||
| Connector material | TPU | ||||||||
| Connector color | Black | ||||||||
| Locking nut material | Zinc die-cast, nickel-plated | ||||||||
| Seal material | FKM | ||||||||
| Tightening torque | 0.4 Nm | ||||||||
| Width across flats | 9 | ||||||||
| Cable | 5 m, 4-wire, PVC | ||||||||
| Jacket material | PVC | ||||||||
| Jacket color | Gray | ||||||||
| Cable diameter | 4.8 mm | ||||||||
| Conductor cross section | 0.25 mm² | ||||||||
| Shielding | Unshielded | ||||||||
|
|||||||||
| Nominal voltage, cable | 300 V AC | ||||||||
| Test voltage, cable | 2,000 V AC | ||||||||
|
|||||||||
| Rated impulse voltage | 1.5 kV | ||||||||
| Current loading | ≤ 4 A | ||||||||
| Signal type | Sensor/actuator cable | ||||||||
| Application | Zones with chemicals
Uncontaminated zones |
||||||||
| Authorizations | UL | ||||||||
| UL File No. | E335179 | ||||||||
| Enclosure rating | IP65 / IP66K / IP67 | ||||||||
|
|||||||||
| Contamination rating | 3 | ||||||||
| Insulation resistance | 100 MΩ | ||||||||
| Overvoltage category | III | ||||||||
| Specific insulation resistance | 30 mΩ | ||||||||
| Thermal resistance, piping | Flame retardant according to UL 1581 VW1 / CSA FT1 | ||||||||
SICK YF8U14-050VA3XLEAX (2095889)
Connectors and cables: Sensor/actuator cable
SKU: RWHD55Y1T
| Weight | 0.2 kg |
|---|
