| Supply voltage UB | 10 V DC … 30 V DC 1) |
| Ripple | < 5 Vpp 2) |
| Current consumption | 50 mA 3) |
| Switching output | NPN, PNP |
| Switching mode | Light/dark switching |
| Switching mode selector | Selectable via PNP/NPN selector, selectable via light/dark selector |
| Output current Imax. | ≤ 100 mA |
| Response time | ≤ 500 µs 4) |
| Switching frequency | 1,000 Hz 5) |
| Time functions | Switch-on delay
Off delay |
| Delay time | Adjustable via time delay selector switch, 0.5 s … 10 s |
| Connection type | Male connector M12, 4-pin |
| Circuit protection | A 6)
C 7) D 8) |
| Protection class | II 9) |
| Weight | 330 g |
| Front screen heating | ✔ 10) |
| Housing material | Metal, zinc diecast |
| Optics material | Plastic, PMMA |
| Enclosure rating | IP69K |
| Test input sender off | TE to 0 V |
| Ambient operating temperature | –40 °C … +60 °C |
| Ambient temperature, storage | –40 °C … +75 °C |
| Functional principle | Photoelectric proximity sensor |
| Functional principle detail | Background suppression |
| Dimensions (W x H x D) | 27 mm x 87.5 mm x 65 mm |
| Housing design (light emission) | Rectangular |
| Sensing range max. | 100 mm … 2,500 mm 1) |
| Sensing range | 100 mm … 2,500 mm 1) |
| Type of light | Infrared light |
| Light source | LED 2) |
| Light spot size (distance) | Ø 80 mm (2,500 mm) |
| Adjustment | Potentiometer |
