Supply voltage | 10 V DC … 30 V DC |
Ripple | < 10 % |
Current consumption | 40 mA |
Switching frequency | 10 kHz |
Response time | ≤ 100 µs |
Stability of response time | ± 20 µs |
Jitter | 40 µs |
Switching output | PNP/NPN |
Switching output (voltage) | PNP: HIGH = UV ≤ 2 V / LOW approx. 0 V
NPN: HIGH = approx. UV / LOW ≤ 2 V |
Switching mode | Light/dark switching |
Output current Imax. | 100 mA |
Initialization time | 100 ms |
Connection type | Male connector M8, 4-pin |
Protection class | III 1) |
Circuit protection | UV connections, reverse polarity protected
Output Q short-circuit protected Interference pulse suppression |
Enclosure rating | IP65 |
Weight | Approx. 36 g … 160 g 2) |
Housing material | Aluminum |
Functional principle | Optical detection principle |
Dimensions (W x H x D) | 10 mm x 110 mm x 74 mm |
Fork width | 80 mm |
Fork depth | 59 mm |
Minimum detectable object (MDO) | 0.2 mm |
Label detection | ✔ |
Light source | LED, infrared, Infrared light |
Adjustment | Plus/minus button (Sensitivity, light/dark switching, key lock) |
Teach-in mode | — |
Output function | Light/darkswitching, selectable via button |
