Supply voltage | 10 V DC … 30 V DC |
Ripple | ≤ 10 Vpp 1) |
Voltage drop | ≤ 2 V |
Time delay before availability | ≤ 50 ms |
Hysteresis | 3 % … 15 % 2) |
Reproducibility | ≤ 2 % |
Temperature drift (of Sr) | ± 10 % |
Continuous current Ia | ≤ 200 mA |
No load current | 12.5 mA |
Cable gland clamping area | M20 1.5 |
Wire size | ≤ 2.5 mm² |
Short-circuit protection | ✔ |
Power-up pulse protection | ✔ |
Shock and vibration resistance | 30 g, 11 ms / 10 … 55 Hz, 1 mm |
Ambient operating temperature | –25 °C … +85 °C |
Ambient temperature, storage | –40 °C … +85 °C |
Housing material | Plastic, PA 66 |
Sensing face material | Plastic, PA 66 |
Tightening torque, max. | 1.8 Nm |
Protection class | II 3) |
UL File No. | E348498 |
Housing | Rectangular |
Housing | Standard design |
Dimensions (W x H x D) | 40 mm x 40 mm x 118 mm |
Sensing range Sn | 20 mm |
Safe sensing range Sa | 16.2 mm |
Installation type | Flush |
Switching frequency | 150 Hz |
Connection type | Cable gland |
Switching output | PNP |
Switching output detail | PNP |
Output function | Complementary |
Electrical wiring | DC 4-wire |
Enclosure rating | IP67, IP68, IP69K |
Special applications | Difficult application conditions |
Unit weight | 0.218 Kilograms |
Net unit weight | 0.218 Kilograms |
Unit volume | 313.875 Cubic Centimetres (cm³) |
Country of origin | Malaysia |
EAN | 4047084363634 |
