Supply voltage UB 10 V DC … 30 V DC 1)
Ripple ± 10 % 2)
Current consumption 30 mA 3)
Protection class III
Digital output
Type PNP
Switching mode Light/dark switching
Switching mode selector Selectable via light/dark selector
Signal voltage PNP HIGH/LOW VS – (≤ 3 V) / approx. 0 V
Output current Imax. ≤ 100 mA 4)
Response time < 625 µs 5)
Switching frequency 1,000 Hz 6
Enclosure rating IP67
Ambient operating temperature –25 °C … +55 °C 1)
Ambient temperature, storage –40 °C … +70 °C
Housing Rectangular
Dimensions (W x H x D) 12 mm x 31.5 mm x 21 mm
Connection Male connector M8, 4-pin
Material
Housing Plastic, ABS/PC
Front screen Plastic, PMMA
Weight 20 g
