Specifications
| Device short name | MT400/630 |
|---|---|
| Product or component type | Motor mechanism |
| Device application | Automatic spring charging |
| Range compatibility | ComPacT NSX400 ComPacT NSX630 ComPacT NSX400 DC ComPacT NSX630 DC |
| control type | Standard |
| [Uc] control circuit voltage | 208…277 V AC 60 Hz 220…240 V AC 50/60 Hz |
| circuit breaker mounting mode | Fixed |
| circuit breaker frame rated current | 400 A 630 A |
| Control signal type | Impulse Maintained |
|---|---|
| circuit breaker response time | < 700 ms open < 80 ms closed |
| Maximum operating frequency | 4 per minute |
| Maximum power consumption in VA | 500 VA closing 500 VA opening |
| Locking options description | Padlocking in OFF position 1 to 3 padlocks Ø 5 to Ø 8 |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 19.800 cm |
| Package 1 Width | 17.500 cm |
| Package 1 Length | 17.500 cm |
| Package 1 Weight | 3.104 kg |
