Schneider 33532 Micrologic 5.0 A trip unit

LSI – for NS 630b..1600 drawout
SKU: RW2800Y1T
Main
Range ComPacT
Range of product ComPacT NS630b…1600 new generation
Product or component type Trip unit
Trip unit name MicroLogic 5.0 A
Trip unit technology Electronic
Range compatibility ComPacT NS630b…1600
Device application Distribution
Number of poles 3P
4P
Protected poles description 3t + N/2
4t
3t
Trip unit protection functions Selective protection
Protection type for short time short-circuit protection
for overload protection (long time)
for instantaneous short-circuit protection
Trip unit rating 630 A at 50 °C
800 A at 50 °C
1000 A at 50 °C
1250 A at 50 °C
1600 A at 50 °C
Network type CA
Network frequency 50/60 Hz
Circuit breaker mounting mode Drawout
Complementary
Long-time pick-up adjustment type Ir (thermal protection) Adjustable 9 settings
[Ir] long-time protection pick-up adjustment range 0.4…1 x In
Long-time protection delay adjustment type tr Adjustable 9 settings
[tr] long-time protection delay adjustment range 0.7…16.6 s at 7.2 x Ir
0.7…24 s at 6 x Ir
12.5…600 s at 1.5 x Ir
Thermal memory 20 mn
Short-time protection pick-up adjustment type Isd Adjustable 9 settings
[Isd] Short-time protection pick-up adjustment range 1.5…10 x Ir
Short-time protection delay adjustment type tsd Adjustable
[tsd] Short-time protection delay adjustment range 0…0.4 s I²t=off
0.1…0.4 s I²t=on
Instantaneous protection pick-up adjustment type Ii Adjustable 9 settings
[Ii] instantaneous protection pick-up adjustment range 2…15 x In
Off
Earth-leakage protection Without
Zone selective interlocking ZSI With
Local signalling 3 LEDs (red) for electrical fault
1 LED (red) for internal error
Display type Digital display
Type of measurement Ammeter
Communication of data Measurement readout
Protection and alarm settings
Environment
Ambient air temperature for operation -25…70 °C
Ambient air temperature for storage -40…85 °C
Packing Units
Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 6.7 cm
Package 1 Width 7.9 cm
Package 1 Length 21.6 cm
Package 1 Weight 368.0 g
Weight 0.5 kg
