| Product or Component Type | Dry Sealed Transformer |
|---|---|
| Primary to Secondary Voltage | 208 V 120/240 V |
| Full Capacity Taps | 0 |
| Enclosure Code | 7A |
|---|---|
| Phase | 1 phase |
| Power Rating | 1 kVA |
| Temperature rise | 115 °C |
| Height | 8.13 in (206.50 mm) |
| Width | 6.94 in (176.28 mm) |
| Depth | 5.31 in (134.87 mm) |
| Enclosure mounting | Wall mounted |
| Enclosure Material | Painted sheet steel |
| Enclosure Type | NEMA 3R |
|---|---|
| Insulation temperature | 356 °F (180 °C) |
| Product Certifications | UL Listed CSA cULus |
| Category | US10PE216277 |
|---|---|
| Discount Schedule | 0PE2 |
| GTIN | 785901099451 |
| Returnability | Yes |
| Country of origin | US |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 9.00 in (22.86 cm) |
| Package 1 Width | 10.10 in (25.654 cm) |
| Package 1 Length | 11.30 in (28.702 cm) |
| Package 1 Weight | 21.200 lb(US) (9.616 kg) |
