| Weight | 1 kg |
|---|
Rotork SOLDO SYC4200-1YD23A4 Limit Switch Box
SY: Box = Copper free aluminium enclosrue
C4: Switch = Magnetic reed SPDT, hermetically sealed, up to SlL3, Exia ready, (Switch gty: 1,2,3,4; Terminal digit: 0; temp digit: L, P)
2: Switch Qty = N° 2 Switch (related to switch description)
0: Terminals = Pre-wired terminal strip with additional extra poles for solenoid valve connection (for switches 01,03,1F,06 C4,C8, N1, N3,N4,32,70,62,73.75)
0: Coating = Black powder coating (SY series)
1: Cable entries = 2 cable cable entries 1/2″ NPT
Y: Visual position indicator = 3D 90° yellow-back (open-close) visual position indicator
D: Approval = ATEX and IECEx certified box with SIL2 approval
2: Marking = Certification marking: Ex II 2GD Exd IIC
3: IP protection rating = Weather proof IP66/IP68
A: Temperature = Ambient Temp. range: -20 … +80°C
4: Material = Copper free aluminium heavy duty body and cover (SY series)
SKU: RW3750Y2Z
