Article number:AE 1076.500
MaterialEnclosure: Sheet steel
Door: Sheet steel, all-round foamed-in PU seal
Door: Sheet steel, all-round foamed-in PU seal
Surface finishEnclosure and door: Dipcoat primed, powder-coated on the outside, textured paint
Mounting plate: Zinc-plated
Mounting plate: Zinc-plated
ColourRAL 7035
Supply includesEnclosure with hinged door(s), of all-round solid construction
Gland plate(s) in enclosure base
Mounting plate
Lock: 3 mm double-bit
Gland plate(s) in enclosure base
Mounting plate
Lock: 3 mm double-bit
Protection category NEMANEMA 4
Protection category to IEC 60 529IP 66
IK CodeIK08
DimensionsWidth: 600 mm
Height: 760 mm
Depth: 210 mm
Height: 760 mm
Depth: 210 mm
Material thickness – door2 mm
Material thickness – enclosure1.38 mm
Material thickness of mounting plate3 mm
Dimensions mounting plate (W x H)549 mm x 730 mm
Number of doors1
Interchangeable door hingeYes
Number of locks2
LockLock version: Cam
Number of locks: 2
Lock insert: 3 mm double-bit
Number of locks: 2
Lock insert: 3 mm double-bit
Gland plateSize: 5
Qty.: 1
Qty.: 1
Basic materialSheet steel
Packs of1 pc(s).
Net weight28.5 kg
Gross weight30.3 kg
Customs tariff number94032080
EAN4028177252356
ECLASS 8.027180101
Product descriptionAE Compact enclosure, WHD: 600x760x210 mm, Sheet steel, with mounting plate, single-door, with two cam locks
