Rexroth HCS02.1E-W0054-A-03-NNNN (R911298373)

Product attributes
EPLAN	https://ecad-configuration.boschrexroth.com/?rootpartnr=BOS.HCS02.1E-W0054-A-03-NNNN**&downloads=true
Cooling type	internal air cooling
Maximum current [A]	54
Continuous current [A]	20.6
Width [mm]	105
Height [mm]	251.5
Depth [mm]	352
International protection code	IP20
Nominal mains frequency [Hz]	50-60
Maximum power (without choke) [kW]	12
Continuous power (without choke) [kW]	7
Max. power (with power choke) [kW]	16
Continuous power (with power choke) [kW]	10
max. output frequency (@4 kHz switching frequency) [Hz]	0-400
max. output frequency (@8 kHz switching frequency) [Hz]	0-800
max. output frequency (@12 kHz switching frequency) [Hz]	0-1200
max. output frequency (@16 kHz switching frequency) [Hz]	0-1600
Power supply voltage (1 AC) [V]	200-250
Power supply voltage (3 AC) [V]	200-500
Output voltage	3 x AC 0 … Mains connection voltage V
Weight [kg]	7.16

Weight	8 kg
