Supply voltage (V): 24V
Type of supply voltage U1: DC
Power consumption DC: 3W
Max. device circuit breaker: Max. conductor cross section
Number of del. aux. contacts: 2
Voltage AC1 safety cont.: 240V
Max. current AC1 safety cont.: 6A
Voltage DC1 safety cont.: 24V
Max. current DC1 safety cont.: 6A
Voltage AC15 safety cont.: 230V
Max. current AC15 safety cont.: 4A
Voltage DC13 safety cont.: 24V
Safety contacts: AC at UL: 240 VAC G. P.
Safety contacts: pilot duty: B300, R300
Relay contact material: AgSnO2
Addit. contact details relay: + 0.2 µm Au
Ambient temperature: -10 TO 55°C
Humidity rating 93 % r. h. at 40°C
Terminal style: fixed
Flex. cond. c/s AWG info: 24 – 10 AWG
Height dimension: 87 mm
Width dimension: 45 mm
Depth dimension: 121 mm
Net weight: 255 g
Gross weight: 265 g
