Female cordset single-ended M12 straight A-coded, 4-pin, PUR cable blue, NAMUR
| Connector 1 |
|
|
| Connection |
|
socket |
| Construction type |
|
M12 |
| Style |
|
straight |
| Locking |
|
screw connection |
| Number of pins |
|
4 |
| Coding |
|
A-coded |
|
| Connector 2 |
|
|
|
|
| Operating voltage |
UB |
max. 250 V AC/DC |
| Operating current |
IB |
4 A |
| Resistance per unit length |
R’ |
max. 0.057 Ω/m |
| Capacitance per unit length |
C’ |
109 nF/km |
| Inductance per unit length |
L’ |
0.49 mH/km |
| Plug connector |
|
|
| Tightening torque |
|
0.6 Nm |
| Loosening protection |
|
available |
| Tool installation |
|
straight knurling and hexagon nut SW = 14 mm |
| Mating cycles |
|
min. 100 |
|
| Degree of protection |
|
IP68 / IP69 |
| Cable |
|
according to IEC/EN 60228 (DIN VDE 0295) class 6 |
| Sheath diameter |
|
4.8 mm |
| Bending radius |
|
> 15 x cable diameter, movable installation
> 10 x cable diameter, fixed installation |
| Sheath color |
|
blue (similar to RAL 5015) |
| Number of cores |
|
4 |
| Core cross section |
|
0.34 mm2 |
| Cores color |
|
Core 1: brown
Core 2: white
Core 3: blue
Core 4: black |
| Core construction |
|
42 x 0.1 mm ∅ |
| Length |
L |
5 m |
| Cable code |
|
Li FY 11Y 4 x 0.34 |
|
| Mass |
|
147.82 g |
