| Sensor range | 9.5 mm ± 3 mm | ||||
| Light source | LED | ||||
| Light type | Visible green/red/blue, modulated light | ||||
| Light spot representation | 1 mm x 4 mm | ||||
| Angle deviation | max. ± 3° | ||||
| Ambient light limit | |||||
|
|||||
| Teach-in | static Teach-In | ||||
| Operating voltage | UB | 10 … 30 V DC |
| Ripple | 10 % | |
| No-load supply current | I0 | ≤ 70 mA |
| Degree of protection | IP67 | ||||||||||
| Connection | 5-pin, M12 x 1 connector | ||||||||||
| Material | |||||||||||
|
|||||||||||
| Mass | 200 g | ||||||||||
| Dimensions | |||||||||||
|
|||||||||||
