Operating Pressure: | 0…400 bar |
Output Type: | 0 … 20 mA |
Port Type: | BSPP outer thread |
Switch Option: | 2 switching ouputs |
Weight: | Approx. 300 g |
Industry: | Mobile |
Burst Pressure: | 1700 bar |
Brand: | SensoControl |
Electrical Connection: | Circular connector M12x1 5-pole |
Length: | n.a |
Port Size: | G 1/4″ BSPP outer thread |
Application: | Industrial applications |
Product Type: | Pressure Controller |
Response Time: | ≤ 10 ms |
Technology: | Pressure |
Height: | n.a |
Division: | High Pressure Connectors Europe Division |
Body Material: | Painted zinc die cast Z 410 |
Width: | 39,5 mm |
Product Style: | Display sensor |
Specifications Met: | CE |
Operating Temperature: | -20…+85 °C (-4…185°F) |
Parker SCPSD-400-14-15 Pressure Controlle
The PressureController combines the functions of a pressure switch, a pressure sensor and a display device.
JG-1600Y
Weight | 0.3 kg |
---|
