Ethernet Interface
-
10/100BaseT(X) Ports (RJ45 connector)
- 1
-
100BaseFX Ports (single-mode SC connector)
- 1
-
Magnetic Isolation Protection
- 1.5 kV (built-in)
- 1.5 kV (built-in)
Power Parameters
-
Input Current
- 12 to 48 VDC, 265 mA (Max.)
-
Input Voltage
- 12 to 48 VDC
-
Overload Current Protection
- Supported
-
Power Connector
- Terminal block
-
Reverse Polarity Protection
- Supported
Physical Characteristics
-
Housing
- Metal
-
IP Rating
- IP30
-
Dimensions
- 30 x 125 x 79 mm (1.19 x 4.92 x 3.11 in)
-
Weight
- 170 g (0.37 lb)
-
Installation
- DIN-rail mounting
Environmental Limits
-
Operating Temperature
- -40 to 75°C (-40 to 167°F)
-
Storage Temperature (package included)
- -40 to 75°C (-40 to 167°F)
-
Ambient Relative Humidity
-
5 to 95% (non-condensing)
-
