Processing Type
Store and Forward
MAC Table Size
2 K
Packet Buffer Size
768 kbits
Input Voltage
12/24/48 VDC
Operating Voltage
9.6 to 60 VDC
Input Current
EDS-208 Models: 0.07 A @ 24 VDC
EDS-208-M Models: 0.1 A @ 24 VDC
Connection
1 removable 3-contact terminal block(s)
Overload Current Protection
2.5 A @ 24 VDC
Reverse Polarity Protection
Supported
Housing
Plastic
IP Rating
IP30
Dimensions
40 x 100 x 86.5 mm (1.57 x 3.94 x 3.41 in)
Weight
170 g (0.38 lb)
Installation
DIN-rail mounting
Operating Temperature
-10 to 60°C (14 to 140°F)
Storage Temperature (package included)
-40 to 85°C (-40 to 185°F)
Ambient Relative Humidity
5 to 95% (non-condensing)
