| Performance | |
| Measurement Range (Dew Point) | . -60 to +60ºCdp (-76 to +140ºFdp) |
| Accuracy (Dew Point) | ±2ºCdp (±3.6ºFdp) |
| Repeatability | ±0.2ºCdp (±0.36ºCdp) |
| Long Term Stability | <1% per annum |
| Calibration | Traceable 8-point calibration certifi cate |
| Electrical Specifi cations | |
| Output Signal | 4-20mA (2-wire) current source |
| Output | Dew point |
| Analog Output Scaled Range | Standard -60 to +60°C (-76 to +140ºF) -50 to +50°C (-58 to +122ºF) -50 to +30°C (-58 to +86ºF) Non-standard available upon request |
| Supply Voltage | 12 to 28 V DC |
| Load Resistance | Max 250 Ω @ 12 V (500 Ω @ 24 V) |
| CE conformity | Approved |
| UL61010-1 & CAN/CSA C22.2 No. 61010-1 | |
| Operating Specifi cations | |
| Operating Temperature | . -40 to +60ºC (-40 to +140ºF) |
| Operating Pressure | 45 MPa (450 barg / 6500 psig) max |
| Overpressure Rating | x 2 operating pressure 90 MPa (900 barg / 13,000 psig) |
| Flow Rate | 1 to 5 Nl/min (2.1 to 10.6 scfh) mounted in standard sampling block; 0 to 10 m/sec (0 to 32.8 fps) direct insertion |
| Thermal Compensation | Characterized over operating range |
| Mechanical Specifi cations | |
| Ingress Protection | IP66 in accordance with standard BS EN60529:1992 NEMA 4 in protection accordance with standard NEMA 250-2003 |
| Housing Material | 316 stainless steel |
| Dimensions | Transmitter plus connector L=132mm x ø45mm (5.19” x ø1.77”) |
| Sensor Guard | Standard: HDPE Guard < 10μm Optional: 316 stainless steel sintered guard < 80μm |
| Process Connection | G½” BSP ¾” – 16 UNF ⅝” – 18 UNF |
| Weight | 150g (5.29oz) |
| Interchangeability | Fully interchangeable transmitter |
| Electrical Connections | Hirshmann GDS Series (DIN 43650-C) |
| Digital Diagnostic Communications | RS485, 2-wire Modbus RTU |
MICHELL SF72 Dew-Point Transmitter
● Dew-point measurement range –60 to +60 °Cdp (-76 to +140°Fdp)
● 316 stainless steel
● Accuracy ±2°Cdp (±3.6°Fdp)
● SKU: RW5100Y5700Y1Z
| Weight | 0.2 kg |
|---|
