[Performance Specification]
Display size: 7″ TFT
Display area: 154.08(W)×85.92(H)
Resolution: 800×480 px
Display color: 16.77M true color
Visual angle: 70/70/60/70(L/R/U/D)
Contrast: 500:1
Backlight: LED
Luminance: 450cd/m²
LCD life: More than 30000 hours
Touch panel: 4-wire precision resistance network (surface hardness 4H)
CPU: ARM RISC 32Bit 800 MHz
Memory: 256MB Flash Memory+128MB Memory
RTC: Built-in RTC
External storage: 1USB Host
Printer port: USB Host/Serial port
Ethernet: 10/100M adaptable Ethernet interface
Bus interface: None
Program download: USB Slave(Micro USB)/U Disk/Ethernet
Communication: COM0: RS232/RS485/RS422.COM2: RS232.
————————————————————————————-
[Electrical Specification]
Input range: DC12V~DC28V,inbuilt isolated power supply
Power: 3.6W@DC24V
Allowable loss of power: <3ms
Insulation resistance: Greater than 50MΩ@ 500V DC
Hi-pot test: 500V AC 1 minute
————————————————————————————–
[Structure specification]
Shell material: Engineering plastics
Shape size: 204×150×34 (mm)
Cutout size: 192×138 (mm)
Weight: 0.5Kg
————————————————————————————–
[Environmental Specification]
Working temperature: 0~50℃
Working humidity: 10~90%RH (non-condensing)
Storage temperature: -20~60℃
Storage humidity:10~90%RH (non-condensing)
Sine vibration test: 10~500Hz, 30m/s², X,Y,Z direction/hour
Cooling mode: Natural air cooling
