Product characteristics
| Measuring range of vibration[mm/s] | 0…25; (RMS) |
| Frequency range[Hz] | 10…1000 |
Application
| Application | vibration transmitter to ISO 10816 |
Electrical data
| Operating voltage[V] | 9.6…32 DC |
| Protection class | III |
| Sensor type | microelectromechanical system (MEMS) |
Inputs / outputs
| Total number of inputs and outputs | 1 |
Outputs
| Analogue current output[mA] | 4…20 |
| Max. load[Ω] | < (Ub – 9,6 V) x 50; Ub = 24 V: 720 |
Measuring/setting range
| Measuring range of vibration[mm/s] | 0…25; (RMS) |
| Frequency range[Hz] | 10…1000 |
| Number of measurement axes | 1 |
Accuracy / deviations
| Measuring error[% of the final value] | < ± 3 |
| Repeatability | < 0,5; (% of the final value) |
| Linearity deviation | 0,25 % |
Operating conditions
| Ambient temperature[°C] | -30…125 | |
| Note on ambient temperature |
|
|
| Storage temperature[°C] | -30…125 | |
| Protection | IP 67; IP 68; IP 69K |
Tests / approvals
| EMC |
|
||||
| Shock resistance |
|
||||
| Vibration resistance |
|
||||
| MTTF[years] | 868 |
Mechanical data
| Weight[g] | 123.5 |
| Type of mounting | set screw |
| Materials | stainless steel (316L/1.4404) |
| Tightening torque[Nm] | 8 |
Accessories
| Items supplied |
|
Remarks
| Pack quantity | 1 pcs. |
Electrical connection
| Connection | Connector: 1 x M12; coding: A |
