Product characteristics
| Measuring range |
|
||
| Process connection | clamp adapter Ø 10 mm | ||
| Installation length EL[mm] | 42 |
Application
| Special feature | Gold-plated contacts |
| Measuring element | 1 x Pt 100; (to DIN EN 60751, class A) |
| Media | liquids and gases |
| Minimum installation depth[mm] | 15 |
Electrical data
| Protection class | III |
Measuring/setting range
| Measuring range |
|
Accuracy / deviations
| Accuracy[K] | ± (0,15 K + 0,002 x|t|) |
Response times
| Dynamic response T05 / T09[s] | 6 / 25; (to DIN EN 60751) |
Operating conditions
| Protection | IP 67 |
Tests / approvals
| MTTF[years] | 11415.5 |
Mechanical data
| Weight[g] | 193.6 |
| Housing | cylindrical |
| Design | measuring probe |
| Dimensions[mm] | Ø 10 / L = 50 |
| Materials | stainless steel |
| Materials (wetted parts) | stainless steel (316L/1.4404) |
| Process connection | clamp adapter Ø 10 mm |
| Probe diameter[mm] | 10 |
| Installation length EL[mm] | 42 |
Remarks
| Remarks |
|
|
| Pack quantity | 1 pcs. |
Electrical connection
| Connection | Cable: 5 m, PUR |
| Connection | Connector: 1 x M12; coding: A; Contacts: gold-plated |
