Product characteristics
| Number of inputs and outputs | Number of digital outputs: 1; Number of analogue outputs: 1 | ||
| Measuring range |
|
||
| Communication interface | IO-Link | ||
| Process connection | threaded connection M18 x 1,5 internal thread | ||
| Installation length EL[mm] | 45 |
Application
| Special feature | Gold-plated contacts | ||
| Measuring element | 1 x Pt 1000; (to DIN EN 60751, class A) | ||
| Media | liquids and gases | ||
| Pressure rating |
|
||
| Minimum installation depth[mm] | 12 |
Electrical data
| Operating voltage[V] | 18…32 DC; (“supply class 2” to cULus) |
| Current consumption[mA] | < 50 |
| Protection class | III |
| Reverse polarity protection | yes |
| Power-on delay time[s] | 1 |
| Integrated watchdog | yes |
Inputs / outputs
| Number of inputs and outputs | Number of digital outputs: 1; Number of analogue outputs: 1 |
Outputs
| Total number of outputs | 2 |
| Output signal | switching signal; analogue signal; IO-Link; (configurable) |
| Electrical design | PNP/NPN |
| Number of digital outputs | 1 |
| Output function | normally open / normally closed; (parameterisable) |
| Max. voltage drop switching output DC[V] | 2.5 |
| Permanent current rating of switching output DC[mA] | 250 |
| Number of analogue outputs | 1 |
| Analogue current output[mA] | 4…20 |
| Max. load[Ω] | 500 |
| Analogue voltage output[V] | 0…10 |
| Min. load resistance[Ω] | 2000 |
| Short-circuit protection | yes |
| Type of short-circuit protection | pulsed |
| Overload protection | yes |
Measuring/setting range
| Probe length L[mm] | 45 | ||
| Measuring range |
|
||
| Factory setting | -40…150 °C / -40…302 °F | ||
| Set point SP |
|
||
| Reset point rP |
|
||
| Analogue start point |
|
||
| Analogue end point |
|
||
| In steps of |
|
| Resolution | |
|---|---|
| Resolution of switching output[K] | 0.1 |
| Resolution of analogue output[K] | current output: MS / 4096; voltage output: MS / 3561 |
| Resolution of display[K] | 0.1 |
Accuracy / deviations
| Switch point accuracy[K] | ± 0,3 + (± 0,1 % MS) |
| Precision analogue output[K] | ± 0,3 + (± 0,1 % MS) |
| Display accuracy[K] | ± 0,3 + (± 0,1 % MS) |
| Temperature coefficient[% of the span / 10 K] | 0,1; (in case of deviation from the reference condition 25 ± 5 °C) |
Response times
| Dynamic response T05 / T09[s] | 1 / 3; (to DIN EN 60751) |
Software / programming
| Parameter setting options | hysteresis / window; normally open / normally closed; switching logic; switch-on/switch-off delay; Damping; Display unit |
Interfaces
| Communication interface | IO-Link | ||||||||
| Transmission type | COM2 (38,4 kBaud) | ||||||||
| IO-Link revision | 1.1 | ||||||||
| Profiles |
|
||||||||
| Min. process cycle time[ms] | 2.3 | ||||||||
| Supported DeviceIDs |
|
Operating conditions
| Ambient temperature[°C] | -25…80 |
| Storage temperature[°C] | -40…100 |
| Protection | IP 67 |
Tests / approvals
| EMC |
|
||||
| Shock resistance |
|
||||
| Vibration resistance |
|
||||
| MTTF[years] | 470 | ||||
| UL approval |
|
Mechanical data
| Weight[g] | 207 |
| Housing | cylindrical |
| Dimensions[mm] | Ø 34 / L = 140 |
| Materials | stainless steel (316L/1.4404); PBT+PC-GF30; PBT-GF20; PC |
| Materials (wetted parts) | stainless steel (316L/1.4404); O-ring: FKM 80 Shore A |
| Process connection | threaded connection M18 x 1,5 internal thread |
| Probe diameter[mm] | 6 |
| Installation length EL[mm] | 45 |
Displays / operating elements
| Display |
|
Remarks
| Remarks |
|
||
| Pack quantity | 1 pcs. |
Electrical connection
| Connection | Connector: 1 x M12; coding: A; Contacts: gold-plated |
