| Number of inputs and outputs | Number of digital outputs: 2 | ||
| Measuring range |
|
||
| Process connection | threaded connection G 1/4 external thread | ||
| Installation length EL[mm] | 50 |
Application
| Special feature | Gold-plated contacts | ||
| Measuring element | 1 x Pt 1000; (to DIN EN 60751, class A) | ||
| Media | liquids and gases | ||
| Medium temperature[°C] | -40…145 | ||
| Pressure rating |
|
Electrical data
| Operating voltage[V] | 9.6…32 DC; (“supply class 2” to cULus) |
| Current consumption[mA] | < 30 |
| Protection class | III |
| Reverse polarity protection | yes |
| Power-on delay time[s] | 0.5 |
Inputs / outputs
| Number of inputs and outputs | Number of digital outputs: 2 |
Outputs
| Total number of outputs | 2 |
| Output signal | switching signal |
| Electrical design | PNP |
| Number of digital outputs | 2 |
| Output function | complementary |
| Max. voltage drop switching output DC[V] | 2 |
| Permanent current rating of switching output DC[mA] | 500 |
| Short-circuit protection | yes |
| Type of short-circuit protection | pulsed |
| Overload protection | yes |
Measuring/setting range
| Probe length L[mm] | 38 | ||
| Measuring range |
|
||
| Set point SP |
|
||
| Reset point rP |
|
Accuracy / deviations
| Temperature drift per 10 K[K] | 0.1 **) |
| Repeatability[K] | ± 0,1 |
| Setting accuracy[K] | ± 3 |
Response times
| Dynamic response T05 / T09[s] | 1 / 3; (to DIN EN 60751) |
Software / programming
| Adjustment of the switch point | setting rings |
Operating conditions
| Ambient temperature[°C] | -40…80 | |||
| Note on ambient temperature |
|
|||
| Storage temperature[°C] | -40…100 | |||
| Protection | IP 67 |
