Product characteristics
| Number of inputs and outputs | Number of analogue outputs: 1 |
| Measuring range[°C] | -50…150 |
| Communication interface | IO-Link |
| Process connection | threaded connection G 1/2 external thread |
| Installation length EL[mm] | 100 |
Application
| Special feature | Gold-plated contacts | ||
| Measuring element | 1 x Pt 1000; (to DIN EN 60751, class A) | ||
| Media | liquids and gases | ||
| Pressure rating |
|
||
| Note on pressure rating |
|
Electrical data
| Operating voltage[V] | 18…32 DC; (“supply class 2” to cULus) |
| Current consumption[mA] | < 50 |
| Protection class | III |
| Reverse polarity protection | yes |
| Power-on delay time[s] | 1 |
Inputs / outputs
| Number of inputs and outputs | Number of analogue outputs: 1 |
Outputs
| Total number of outputs | 1 |
| Output signal | analogue signal; IO-Link; (configurable) |
| Number of analogue outputs | 1 |
| Analogue current output[mA] | 4…20 |
| Max. load[Ω] | 250; ((18…19 V); 19…32 V: 300 Ω) |
| Short-circuit protection | yes |
| Overload protection | yes |
Measuring/setting range
| Probe length L[mm] | 86 |
| Measuring range[°C] | -50…150 |
| Factory setting | -50…150 °C |
| Resolution | |
|---|---|
| Resolution of analogue output[K] | 0.04 |
Accuracy / deviations
| Precision analogue output[K] | ± 0,3 + (± 0,1 % MS) |
| Temperature coefficient[% of the span / 10 K] | 0,1; (in case of deviation from the reference condition 25 ± 5 °C) |
Response times
| Dynamic response T05 / T09[s] | 1 / 3 |
Interfaces
| Communication interface | IO-Link | ||||||
| Transmission type | COM2 (38,4 kBaud) | ||||||
| IO-Link revision | 1.1 | ||||||
| Profiles |
|
||||||
| Min. process cycle time[ms] | 2.3 | ||||||
| Supported DeviceIDs |
|
Operating conditions
| Ambient temperature[°C] | -25…80 |
| Storage temperature[°C] | -40…100 |
| Protection | IP 67; IP 68; IP 69K |
Tests / approvals
| EMC |
|
||
| Shock resistance |
|
||
| Vibration resistance |
|
||
| MTTF[years] | 572 | ||
| UL approval |
|
Mechanical data
| Weight[g] | 134.5 |
| Housing | cylindrical |
| Dimensions[mm] | Ø 18.7 / L = 163.9 |
| Materials | stainless steel (316L/1.4404); PEI; FKM |
| Materials (wetted parts) | stainless steel (316L/1.4404); O-ring: FKM |
| Tightening torque[Nm] | 45 |
| Process connection | threaded connection G 1/2 external thread |
| Probe diameter[mm] | 6 |
| Installation length EL[mm] | 100 |
Displays / operating elements
| Display |
|
Remarks
| Remarks |
|
|
| Pack quantity | 1 pcs. |
Electrical connection
| Connection | Connector: 1 x M12; coding: A; Contacts: gold-plated |
