Product characteristics
| Type of light | red light |
| Housing | threaded type |
Application
| Special feature | polarisation filter |
| Function principle | Retro-reflective sensor |
Electrical data
| Operating voltage[V] | 10…36 DC |
| Current consumption[mA] | 15 |
| Protection class | II |
| Reverse polarity protection | yes |
| Type of light | red light |
| Wave length[nm] | 624 |
Outputs
| Electrical design | PNP |
| Output function | dark-on mode |
| Max. voltage drop switching output DC[V] | 2.5 |
| Permanent current rating of switching output DC[mA] | 200 |
| Switching frequency DC[Hz] | 1000 |
| Short-circuit protection | yes |
| Type of short-circuit protection | pulsed |
| Overload protection | yes |
Detection zone
| Range referred to prismatic reflector[m] | 0.03…4; (Prismatic reflector Ø 80 E20005) |
| Range adjustable | no |
| Max. light spot diameter[mm] | 160 |
| Light spot dimensions refer to | at maximum range |
| Polarisation filter available | yes |
Operating conditions
| Ambient temperature[°C] | -25…60 |
| Protection | IP 67 |
Tests / approvals
| EMC |
|
||
| MTTF[years] | 509 |
Mechanical data
| Weight[g] | 49.75 | |
| Housing | threaded type | |
| Dimensions[mm] | M18 x 1 / L = 60 | |
| Thread designation | M18 x 1 | |
| Materials | housing: stainless steel (316L/1.4404) | |
| Lens material |
|
Displays / operating elements
| Display |
|
