| Electrical design | PNP |
| Output function | normally open |
| Sensing range[mm] | 2 |
| Housing | threaded type |
| Dimensions[mm] | M12 x 1 / L = 35 |
| Operating voltage[V] | 10…36 DC |
| Current consumption[mA] | 15; (24 V) |
| Protection class | II |
| Reverse polarity protection | yes |
| Electrical design | PNP |
| Output function | normally open |
| Max. voltage drop switching output DC[V] | 2.5 |
| Permanent current rating of switching output DC[mA] | 150 |
| Switching frequency DC[Hz] | 1500 |
| Short-circuit protection | yes |
| Type of short-circuit protection | pulsed |
| Overload protection | yes |
