| DQ450DBZ TOP DRIVE PARTS |
| SKU / Art. No. |
Description |
名称 |
Part No. |
Weight |
| JG-96800Y |
BACKUP TONG |
背钳 |
DQ004.01.001 |
100 kg |
| JG-2030U |
WASHPIPE SUBASSEMBLY |
冲管组件 |
DQ004.04.00 |
20 kg |
| JG-4917U |
REVERSE TORQUE BEAM |
反扭矩梁 |
DQ004.11.00 |
50 kg |
| JG-49800Y |
POWER TRANSMISSION SYSTEM |
动力传动系统 |
DQ004.12.00 |
200 kg |
| JG-2300Y |
BRAKE CARRIER |
制动器载板 |
DQ004.15 |
50 kg |
| JG-19800Y |
DISC BRAKE MCDELSKD80 |
盘刹总成;SKD80 |
|
100 kg |
| JG-436U |
LIFTING BAIL SHAFT |
提环轴 |
DQ001.24 |
50 kg |
| JG-3U |
POSITIONING BLOCK 1 |
限位块1 |
DQ001.22 |
2 kg |
| JG-38000Y |
AUTOMATIC IBOP |
自动内防喷器 |
DQ001.02.03 |
100 kg |
| JG-988U |
CUT-OFF OIL CYLINDER (R) |
关断油缸(右) |
DQ004.02.01.00 |
20 kg |
| JG-6570Y |
CUT-OFF OIL CYLINDER (L) |
关断油缸(左) |
DQ004.02.02.00 |
20 kg |
| JG-2450Y |
TORQUE RISE DEVICE |
增扭装置 |
DQ001.02.09.00 |
20 kg |
| JG-2Y |
BOLT M10 X 20 |
螺栓;M10×20;GB/T32.1;8.8级 |
GB/T321 |
0.1 kg |
| JG-385U |
UPPER PACKING BOX GLAND |
上盘根盒压盖 |
DQ001.26.02 |
5 kg |
| JG-265U |
UPPER PACKING BOX |
上盘根盒 |
SL001.05.02 |
5 kg |
| JG-1108Y |
UPPER PRESSING SLEEVE |
上密封套 |
DQ004.04.01 |
3 kg |
| JG-38U |
MUD PACKING |
泥浆盘根 |
SL001.05.04 |
1 kg |
| JG-140Y |
UPPER BUSHING RING |
下衬环 |
SL001.05.08 |
1 kg |
| JG-1450Y |
MUD PIPE |
泥浆管 |
DQ004.04.02 |
10 kg |
| JG-1750Y |
LOWER PACKING BOX |
下盘根盒 |
SL001.05.10 |
5 kg |
| JG-178U |
LOWER PRESSING SLEEVE |
下密封套 |
DQ004.04.03 |
3 kg |
| JG-2560Y |
LOWER PACKING BOX PRESSURE COVER |
下盘根盒压盖 |
DQ004.04.04 |
5 kg |
| JG-5800Y |
TEMPERATURE SENSOR MODEL CXPTZPT100-02-K-22D-q8-3 L=200 1=150 (-40-85’C) |
温度传感器;CXPTZPT100-0.2-K-22D-Φ8-3 |
|
2 kg |
| JG-9800Y |
EXPLOSION-PROOF ELECTRIC MOTOR MODEL YB2-160M-4 B35 (600V/50HZ) |
交流电机;YB2-160M-4 11kW 600V/50HZ B35 |
|
120 kg |
| JG-4U |
PIPE CLAMP BASE PLATE 1 MODEL T30 |
垫块(配焊） |
|
0.5 kg |
| JG-118U |
oiLSUCTiON filter modeltfioc x iool |
吸油过滤器;TF-100×100L |
|
5 kg |
| JG-30U |
RIGHT ANGLE JOINT MODEL 2C9-36 |
卡套接头;2C9-36RN |
|
2 kg |
| JG-10U |
BALL VALVE MODEL QHF-16P-1 |
球阀;2PC-Q11F-16P-NPT1″ |
|
0.5 kg |
| JG-25Y |
CROSSOVER SUB MODEL ICG-36-16 |
卡套接头;1CG-36-16 |
|
0.1 kg |
| JG-20U |
CROSSOVER SUB MODEL 1CG-36-16RN |
卡套接头;1CG-36-16RN |
|
0.1 kg |
| JG-21U |
HOSE ASSEMBLY MODEL 87391-20-20/20411-45-20TXIS-20X750 |
软管总成 |
|
3 kg |
| JG-1Y |
SCREW MODEL M12X 25 GB/T70.1 |
圆柱头内六角螺钉;M12×25;GB/T70.1;A4-70 |
GB/T70.1 |
0.1 kg |
| JG-23900Y |
DOUBLE PUMP SET MODEL A10V028DR/31R-PSC12K01 + AZPF-U-014RRR20KB |
柱塞泵;A10V028DR/31R-PSC12K01 |
|
50 kg |
| JG-1580Y |
EX-PROOF ELECTRIC HEATER MODELSJB2-2 (HEATER HEIGHT LESS THAN300MM) |
防爆电加热器;SJB2-2 220V/50HZ; |
|
30 kg |
| JG-1008U |
ACCUMULATOR MODEL HXQ |
蓄能器;HXQ-10/20-L-Y |
|
30 kg |
| JG-28Y |
CONNECTION BLOCK 2 |
联接块二 |
DQ004.07.01.07 |
0.1 kg |
| JG-8Y |
MOTOR GASKET |
电机垫块 |
DQ004.07.01.08 |
0.1 kg |
| JG-5U |
BALL VALVE MODEL Q11F-16P-1/2 |
球阀;2PC-Q11F-16P-NPT1/2″ |
|
0.1 kg |
| JG-88U |
OIL RETURN FILTER MODEL SP-10 X 25 |
过滤器;SP-10×25 |
|
5 kg |
| JG-83Y |
CROSSOVER SUB MODEL 1CH-45-42 |
卡套接头;1CH-45-42; |
|
0.1 kg |
| JG-11U |
QUICK-CHANGE CONNECTOR MODEL H8-63.66M |
快换接头;H8-63.66M |
|
0.1 kg |
| JG-28Y |
CLAMP PAD MODEL T20 |
垫块(配焊） |
|
0.1 kg |
| JG-280Y |
DUAL ACCUMULATOR BRACKET |
双蓄能器支架 |
DQ004.07.02.01.00 |
3 kg |
| JG-25Y |
ACCUMULATOR BASE PAD |
垫块(配焊） |
|
0.1 kg |
| JG-5113U |
MANUAL IBOP |
手动内防喷器 |
DQ001.02.02 |
100 kg |
| JG-20300U |
BOP ASSEMBLY |
防喷器总成 |
DQ004.02.001 |
150 kg |
