| HHF-1300/1600 Liner Wash Pump Assembly Parts List |
|
|
|
|
| No. |
P/N(HHF-1300/1600) |
Description |
Qty |
| 1 |
11-3161-0801-00-1 |
Guard |
1 |
| 11-3161-0801-00-2 |
Guard |
1 |
| 2 |
11-3161-0802 |
Belt pulley |
1 |
| 3 |
11-3161-0803-00 |
Seat assembly |
1 |
| 4 |
11-3161-0804 |
Joint, short, NPT1-1-11 1/2NPSC |
1 |
| 5 |
11-3161-0805 |
Joint, NPT1 |
1 |
| 6 |
11-3161-0806 |
Joint, 1-11 1/2NPSC -1 1/4-12UNF-2A |
1 |
| 7 |
11-3161-0807 |
Joint, NPT2 1/2 |
1 |
| 8 |
11-3161-0808 |
Joint, short, NPT2 1/2 |
1 |
| 9 |
11-3161-0818 |
Hose, L=1500 |
1 |
| 10 |
11-3161-0809-00 |
Hose joint, 022*037 |
2 |
| 11 |
11-3161-0810 |
Elbow, 90°, NPT1 |
2 |
| 12 |
11-3161-0811 |
Connecting board |
2 |
| 13 |
11-3161-0812-00 |
Water case |
1 |
| 14 |
11-3161-0813-00 |
Case cover |
1 |
| 15 |
11-3161-0814 |
Pipe plug, NPT2 1/2 |
1 |
| 16 |
11-3161-0815 |
Shim |
2 |
| 17 |
11-3161-0816 |
Flange, NPT1 |
2 |
| 18 |
11-3161-0819 |
Screw, 5/16-18 U N C-2 A*2 5 |
2 |
| 19 |
B1171-A3708 |
V belt, A3708 |
2 |
| 20 |
11-3161-0820 |
Pipe clamp, No:3 |
2 |
| 21 |
11-3161-0821 |
Hose, L=750 |
1 |
| 22 |
11-3161-0822 |
Elbow 90°, NPT2 1/2 |
1 |
| 23 |
11-3161-0823 |
Bolt, 5/8-11UNC-2A*50 |
4 |
| 24 |
B0848-16-32 |
Flat washer, 16 |
8 |
| 25 |
B0093-16-59 |
Spring washer, 16 |
4 |
| 26 |
11-3161-0824 |
Bolt 1/2-13UNC-2A*40 |
4 |
| 27 |
B0093-14-59 |
Spring washer, 14 |
12 |
| 28 |
B0096-14-59 |
Washer, 14 |
4 |
| 29 |
11-3161-0825 |
Bolt, 1/2-13UNC-2A*60 |
8 |
| 30 |
11-3161-0826 |
Nut, 1/2-13UNC-2B |
8 |
| 31 |
11-3161-0827 |
Spraying pump |
1 |
| 32 |
11-3161-0828 |
Ball valve, 1-11 1/2NPSC |
1 |
| 33 |
11-3161-0817-00 |
Support |
1 |
