| HHF-1300/1600 KB-75 Damper Assembly Parts List |
| No. |
P/N(HHF-1300/1600) |
Description |
Qty |
| 1 |
11-3161-2701 |
Ring gasket, R39 |
1 |
| 2 |
11-3161-2702 |
Plug |
1 |
| 3 |
11-3161-2703-00 |
Diaphragm (bladder) |
1 |
| 4 |
11-3161-2704-00 |
Dampener body |
1 |
| 5 |
11-3161-2705 |
Cover |
1 |
| 6 |
11-3161-2706 |
Tee, NPT1/4 |
1 |
| 7 |
11-3161-2707 |
Joint, NPT1/4 |
1 |
| 8 |
11-3161-2708-00 |
Guard, pressure gauge |
1 |
| 9 |
11-3161-2709-00 |
Bleeder valve |
1 |
| 10 |
11-3161-2710-01 |
Pressure, gauge,0~25MPa(0~3630PSi) |
1 |
| 11 |
11-3161-2710-02 |
Check valve |
1 |
| 12 |
11-3161-2710 |
Washer |
1 |
| R1 |
11-3161-2704-02 |
Stud bolt, 1 1/2-8UN(12UNF)-2A*120 |
12 |
| R2 |
11-3161-2704-03 |
Nut,1 1/2-8UN-2B (SPL) |
12 |
| R3 |
11-3161-2704-04 |
Stud bolt, 1 1/4-8UN(12UNF)-2A*100 |
8 |
| R4 |
11-3161-2704-05 |
Nut, 1 1/4-8UN-2B (SPL) |
8 |
