| HHF-1300/1600 Cylinder (block) assembly |
| No. |
Part No. (HHF-1300/1600) |
Part Name |
Qty. |
| 1 |
11-3161-0501-01 |
Fluid end (not nickel plating) |
1 |
| 2 |
11-3161-0501-02 |
Stud bolt: 1-8UNC (14UNS) -2A*185 |
12 |
| 3 |
11-3161-0501-03 |
Nut: 1-8UNC-2B (SPL) |
12 |
| 4 |
11-3161-0501-04 |
Stud bolt: 1 1/2-8UN (12UNF) -2A*170 |
10 |
| 5 |
11-3161-0501-05 |
Stud bolt: 1 1/2-8UN (12UNF) -2A*120 |
10 |
| 6 |
11-3161-0501-06 |
Nut: 1 1/2-8UN-2B (SPL) |
20 |
| 7 |
11-3161-0501-07 |
Stud bolt: 1 1/4-8UN (12UNF) -2A*195 |
4 |
| 8 |
11-3161-0501-08 |
Nut: 1 1/4-8UN-2B (SPL) |
4 |
| 9 |
11-3161-0501-09 |
Anaerobic fluid sealant 277 |
1 |
