HBM Z6FC3-50kg (36175) Single Ended Beam Load Cell

JG-247U-H**

Model: Z6FC3-50 kg
Part Number: 36175
Approvals: FM
Capacity: 50 kg OIML C3
Safe Overload: 150% capacity
Construction: Stainless Steel
Cable Color Code: Blue = + Excitation, Black = – Excitation, White = + Signal, Red = – Signal, Green = +Sense, Grey = – Sense
Rated Excitation: 5-10 VDC (maximum of 15 V)
Full Scale Output: 2 mV/V
Input Resistance: 350-400 ohms
Output Resistance: 356 (± 0.12) ohms
Insulation Resistance: 5000 megohms
Operating Temperature Range: 0°F to 150°F
IP Rating: IP68
Cable Length: 10 ft
Cable Diameter: 0.190 polyurethane jacket
Interchangeable Products: Rice Lake RLHBB, RL9018SS, Revere SHB, Tedea Huntleigh 355, Mettler Toledo MTB
Weight 1 kg
