Festo VZBA-1″-GGG-63-32L-F0405-V4V4T (1692215) Ball Valve

Design: 3-way ball valve L-hole
Type of actuation: Mechanical
Sealing principle: Soft
Mounting position: optional
Type of mounting: In-line installation
Connection Process valve: Rp1
Switching position indicator: Slot direction = flow direction
Flange hole pattern: F04 / F05
Inside diameter: 20 mm
Nominal size DN” 25
Valve function: 3/2
Manual override: None
Flow direction: Reversible
Nominal pressure PN: 63
Actuating torque: 22 Nm
Based on standard: EN 10226-1 / ISO 5211
Symbol: 00991888
Medium: Compressed air to ISO 8573-1:2010 [-:-:-] / Inert gases / Water – no water vapour / Neutral fluids / Other media on request
Media temperature: -10 °C … 200 °C
Flow rate Kv L hole: 11.8 m³/h
Note on materials: RoHS-compliant
LABS (PWIS) conformity: VDMA24364 zone III
Material housing: High-alloy stainless steel
Material number housing: 1.4408
Material seals: PTFE / PTFE reinforced
Material ball: High-alloy stainless steel
Material number ball: 1.4408
Material shaft: High-alloy stainless steel
Material number shaft: 1.4401
Product weight: 1600 g
Explosion protectionZone 1 (ATEX) / Zone 2 (ATEX) / Zone 21 (ATEX) / Zone 22 (ATEX)

Weight	1.6 kg
