Technical Data
- Valve function: One-way flow control function
- Pneumatic connection, port 1: G1/8
- Pneumatic connection, port 2: G1/8
- Adjustment component: Knurled screw
- Type of mounting: Either: Front panel mounting With through-hole
- Standard nominal flow rate in flow control direction: 210 l/min
- Standard nominal flow rate in blocked direction: 180 l/min … 275 l/min
- Operating pressure: 0.5 bar … 10 bar
- Ambient temperature: -20 °C … 60 °C
- Material housing: Wrought aluminium alloy
- Explosion protection: The information in the certificate must be observed! Zone 1 (ATEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 22 (ATEX)
- Mounting position: optional
- Symbol: 00991453
- Operating medium: Compressed air to ISO 8573-1:2010 [7:4:4]
- Note on operating and pilot medium: Lubricated operation possible (in which case lubricated operation will always be required)
- LABS (PWIS) conformity: VDMA24364-B1/B2-L
- Media temperature: -20 °C … 60 °C
- Nominal size: 3 mm
- Product weight: 31 g
- Note on materials: RoHS-compliant
- Material seals: NBR
- Material sleeve: POM
- Material adjusting screw: High-alloy steel
- Material nut: Wrought aluminium alloy
