ED201/6 Electro-hydraulic thruster

ED201/6 Electro-hydraulic thruster

Model:

Ed23/5

Ed30/5

Ed40/4

Ed50/6

Ed70/5

Ed80/6

Ed100/6

Ed121/6

Ed201/6

Ed301/6

Ed50/12

Ed80/12

Ed121/12

Ed201/12

Ed301/12

Ed450/12

Ed630/12

Ed121/8

Ed201/8

Ed301/8

Ed450/8

SKU: RW1300Y5100Y3T

Description
Additional information

型号 Model	额定推力 Rated Thrust (N)	额定行程 Rated Stroke (mm)	制动弹簧力 Braking spring force (N)	功率消耗 Power consumptoin (W)	额定电流 Rated Current (A)	额定电压 Rated Voltage (V)	最大操作频率 Max. oprate Feq. (c/h)	重量 Weight (kg)
Ed23/5	220	50	180	165	0.52	380-400	2000	10
Ed30/5	300	50	270	200	0.46	380-400	2000	14
Ed40/4	400	40	270	200	0.46	380-400	2000	15
Ed50/6	500	60	460	210	0.48	380-400	2000	23
Ed70/5	700	50	460	210	0.5	380-400	2000	24
Ed80/6	800	60	750	330	1.42	380-400	2000	25
Ed100/6	1000	60	750	330	1.42	380-400	2000	28
Ed121/6	1250	60	1200	330	1.44	380-400	2000	39
Ed201/6	2000	60	1900	450	1.45	380-400	2000	39
Ed301/6	3000	60	2700	550	1.46	380-400	1500	40
Ed50/12	500	120		210	0.48	380-400	1200	26
Ed80/12	800	120		330	1.42	380-400	1200	27
Ed121/12	1250	120		330	1.44	380-400	1200	39
Ed201/12	2000	120		450	1.45	380-400	1200	39
Ed301/12	3000	120		550	1.46	380-400	900	40
Ed450/12	4500	120		1100	2.56	380-400	900	45
Ed630/12	6300	120		1100	2.4	380-400	630	55
Ed121/8	1250	80		550	1.52	380-400	1200	39
Ed201/8	2000	80		750	1.98	380-400	1200	39
Ed301/8	3000	80		900	2.21	380-400	900	40
Ed450/8	4500	80		1100	2.56	380-400	900	45

Weight	45 kg
