Danfoss 017-520866 Thermostat RT120

Ambient temperature range [°C] [max]	70 °C
Ambient temperature range [°C] [min]	-50 °C
Ambient temperature range [°F] [max]	158 °F
Ambient temperature range [°F] [min]	-58 °F
Approval	CCC CE CMIM DNV EAC GL LLC CDC EURO-TYSK LVD NKK RMRS RoHS RoHS China TYSK
Cap. tube length fraction [in]	78 3/4 in
Capillary tube length [mm]	2000 mm
CE evaluated	Yes
Charge type	Partial
China RoHS compliance	Yes
Contact function	SPDT
Contact rating	AC15=3 A, 400 V AC1=10 A, 400 V AC3=4 A, 400 V DC13=12 W, 220 V LR=28 A, 400 V
Contains batteries	No
Diff. @ Max. range setting[°C] [max]	9 °C
Diff. @ Max. range setting[°C] [min]	1.8 °C
Diff. @ Min. range setting[°C] [max]	30 °C
Diff. @ Min. range setting[°C] [min]	7 °C
Differential type	Adjustable
Electrical conn. Male/Female	Female
Electrical connection	Screwed cable entry
Electrical connection size	2xPg 13.5
Electrical connection standard	DIN 40430
Electrical spec. standard	EN 60947-4/-5
EN 60947 electrical properties	Insulation: 400V Pollution degree: 3 Rated impulse voltage: 4 kV Short circuit prot, fuse: 10A

EN 60947 wiring properties	Flex, ferrules: 0.2-1.5 mm2 Flex, no ferrules: 0.2-2.5 mm2 Solid/stranded: 0.2-2.5 mm2
Enclosure rating IP	IP66
EU RoHS compliance	Yes
EU RoHS exemption clause	No
Max. sensor temperature [°C]	260 °C
Max. sensor temperature [°F]	500 °F
Packing format	Multi pack
Product accessories	Switches accessories
Product description	Thermostat
Quantity per packing format	15 pc
REACH Candidate List substances	Lead (CAS no. 7439-92-1)
Reset function	Auto
SCIP dossier no.	c4c20ce6-4a07-4caa-9394-1e7d8b13ffec
Sensor pocket length min. [in]	4 13/32 in
Sensor pocket length min. [mm]	112 mm
Sensor size (Ø x L) [in]	3/8 x 3 1/8 in
Sensor size (Ø x L) [mm]	9.5 x 80 mm
Sensor type	Remote bulb
Serviceable	Contact systems
Temperature range [°C] [max]	215 °C
Temperature range [°C] [min]	120 °C
Temperature range [°F] [max]	419 °F
Temperature range [°F] [min]	248 °F
