BECKHOFF CX5140-0100

BECKHOFF CX5140-0100

Embedded PC with Intel Atom® E3845
SKU: RW7758Y12Y
Technical data CX5140
Processor Intel Atom® E3845, 1.91 GHz
Number of cores 4
Flash memory slot for CFast card and microSD card, cards not included
Main memory 4 GB DDR3 RAM (not expandable)
1-second UPS integrated (1 MB on CFast card)
Interfaces 2 x RJ45 10/100/1000 Mbit/s, 1 x DVI-I, 4 x USB 2.0, 1 x optional interface
Cooling passive
Diagnostics LED 1 x power, 1 x TC status, 1 x flash access, 2 x bus status
Clock internal battery-backed clock for time and date (battery exchangeable)
Operating system Windows Embedded Compact 7, Windows Embedded Standard 7, Windows 10 IoT Enterprise 2016 LTSB, Windows 10 IoT Enterprise 2019 LTSC, Windows 10 IoT Enterprise 2021 LTSC, TwinCAT/BSD
Control software TwinCAT 2 runtime
TwinCAT 3 runtime (XAR)
I/O connection E-bus or K-bus, automatic recognition
Power supply 24 V DC (-15%/+20%)
Current supply E-bus/K-bus 2 A
Max. power consumption 16 W
Max. power consumption (with loading UPS) 23 W
Max. power consumption E-bus/K-bus 10 W (5 V/max. 2 A)
Weight approx. 1095 g
Dimensions (W x H x D) 142 mm x 100 mm x 92 mm
Relative humidity 95%, no condensation
Operating temperature -25…+60°C
Storage temperature -40…+85°C
Vibration/shock resistance conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission conforms to EN 61000-6-2/EN 61000-6-4
Protection rating IP20
Approvals/markings CE, UL, DNV GL, with CX2900-0107 ordering option: ATEX, IECEx, cFMus
Ex marking ATEX:
II 3 G Ex nA IIC T4 Gc
II 3 D Ex tc IIIC T135 °C Dc
IECEx:
Ex nA IIC T4 Gc
Ex tc IIIC T135 °C Dc
cFMus:
Class I, Division 2, Groups A, B, C, D
Class I, Zone 2, AEx ec IIC T4 Gc
Weight 1.1 kg
