BECKHOFF C9900-C618

BECKHOFF C9900-C618

Multi-touch Panel PC
SKU: RW2313Y12Y
Technical data CP32xx-1600-0020 Options
Device type Multi-touch Panel PC
Housing aluminum housing for mounting arm installation
Mounting arm adapter 4 M6 threaded holes with a distance of 100 x 100 mm and 4 M6 threaded holes with a distance of 70 x 130 mm for connection to a mounting arm system rotatable and tiltable mounting arm adapter for mounting arm systems with 48 mm tube from top or from bottom
Wiring area for up to 6 IP65 connectors, 4 of these are free
Slots for hard disk/flash 1 slot for 2½-inch hard disk/SSD, 1 slot for CFast 2 slots for CFast or 2 slots for 2½-inch hard disk/SSD
Cooling passive through heat sink structure, internal fan for equal heat distribution
to all housing walls
Free space for air circulation 20 cm (7.9″) around the PC required
Extensions 3 M5 threaded holes on the underside of the Control Panel for mounting mechanical extensions toolboard or handle
Protection rating IP65
Operating temperature 0…45°C
Display size/resolution 15″ 1024 x 768, 15.6″ 1366 x 768, 18.5″ 1366 x 768, 19″ 1280 x 1024,
21.5″ 1920 x 1080 or 24″ 1920 x 1080
Touch screen multi-finger touch screen
Processor Intel® Celeron® G3900TE 2.3 GHz, 2 cores (TC2, TC3: 50) up to Intel® Core™ i7 7700(T) 2.9 GHz, 4 cores (TC3: 80)
Motherboard 3½-inch motherboard for 6th/7th generation Intel® Celeron®, Pentium®, Core™ i3/i5/i7
Memory 4 GB DDR4 RAM up to 32 GB DDR4 RAM ex factory
Ethernet 2 x 100/1000BASE-T on-board 3 additional 100/1000BASE-T
RAID on-board SATA RAID 1 controller
Hard disks/flash hard disk, 2½-inch, 320 GB SSD, CFast
Interfaces 1 x USB 3.0 with screw-on cap IP65 in the bottom
1 x M23 socket for power supply
1 x Ethernet 100/1000BASE-T push-pull
Power supply 24 V DC UPS
Operating system – Windows 10 IoT Enterprise
Weight 2 kg
