BECKHOFF C6930-0060

Technical data	C6930-0060	Options
Device type	Control cabinet Industrial PC
Housing	aluminum housing
Installation	mounting sheet at the rear wall	mounting sheet at the right side wall
Slots for hard disk/flash	2 slots for 2½-inch hard disk/SSD, 1 slot for CFast	2 slots for CFast
Free space for air circulation	5 cm (2″) on top and bottom of the PC required
Protection rating	IP20
Operating temperature	0…55°C
Weight of basic configuration	2.1 kg (4.6 lbs)
Dimensions (W x H x D)	90 x 235 x 121 mm (3.5″ x 9.3″ x 4.8″), without mounting plate	with plug-in card slots 70 mm wider and 18 mm deeper
Processor	Intel® Celeron® G3900TE 2.3 GHz, 2 cores (TC2, TC3: 50)	up to Intel® Core™ i7 7700(T) 2.9 GHz, 4 cores (TC3: 80)
Motherboard	3½-inch motherboard for 6th/7th generation Intel® Celeron®, Pentium®, Core™ i3/i5/i7
PCIe®/PCI™ slots	2 PCIe® module slots to plug-in Beckhoff PCIe® modules or to led out interfaces of the motherboard ex factory	2 plug-in card slots PCI™ or PCIe®
Memory	4 GB DDR4 RAM	up to 32 GB DDR4 RAM ex factory
Graphic	integrated in the processor
Ethernet	2 x 100/1000BASE-T on-board	1 additional 100/1000BASE-T
RAID	on-board SATA RAID 1 controller
Hard disks/flash	hard disk, 2½-inch, 320 GB	SSD, CFast
Interfaces	4 x USB 3.0, 1 x RS232, 1 x DVI
Power supply	24 V DC	UPS
Operating system	–	Windows 10 IoT Enterprise

Weight	2.1 kg
