Power: AC/DC Universal
Sensing Beam: Infrared LED
IP Rating: IP67
NEMA / UL Type Rating: NEMA 4X
Supply Voltage: 10-30 V dc / 12-240 V ac
Sensing Mode (General): Opposed
Sensing Mode (Detailed): Emitter
Housing Style: Barrel
Primary Housing Material: Stainless Steel
Max Sensing Distance (mm): 150000
Connection: Integral QD
Quick Disconnect Type: 7/8 in. (Mini)
Operation: N/A
Min Op. Temp. (°C): -40
Max Op. Temp. (°C): 70
Output response time (ms): N/A
Special Feature: Intrinsically Safe: No
Special Feature: Remote Teach: No
Special Feature: Water Detection: No
Delay at Power-up (ms): N/A
Number of Pins: 3
Max Op. Relative Humidity [%]: 90% @ 50°C
Lens Material: Acrylic
Adjustments: N/A
Barrel Diameter (mm): 30
Indicator: LEDs
Opposed Mode Emitter/Receiver: Emitter
Feature: Encapsulated: Yes
Feature: Audible: No
Feature: Chemical Resistant: Yes
Feature: Quick Disconnect: Yes
