Number of Phases:
3-phase
Degree of Protection:
IP21
Enclosure Type NEMA:
Type1
Altitude:
4000 m
Operating Humidity (RHamb):
5 … 95
Sound dB (A):
68 dB(A)
Multiple Battery Information:
Lithium Coin, CR2032, 220 mAh, 3 V, 2 pcs, 6 g
Frequency (f):
47.5 … 63 Hz
Frame Size:
R8
Input Voltage (Uin):
380 … 415 V
Mounting Type:
Wall-mounted
Communication Protocol:
CAN
DeviceNet
EtherNet/IP
MODBUS
Other Bus Systems
PROFIsafe
PROFIBUS
PROFINET IO
Number of Hardware Interfaces:
Industrial Ethernet 0
Other 4
Parallel 0
PROFINET 0
RS-232 0
RS-422 0
RS-485 1
Serial TTY 0
USB 1
Includes:
Control unit
PC connection
Analog Inputs:
2
Analog Outputs:
2
Number of Digital In/Outputs:
6 / 2
Output Current, Normal Use (In):
246 A
Output Current, Light-Overload Use (ILD):
234 A
Output Current, Heavy-Duty Use (IHD):
206 A
Output Power, Normal Use (Pn):
132 kW
Output Power, Light-Overload Use (PLD):
132 kW
Output Power, Heavy-Duty Use (PHD):
110 kW
Power Consumption (@Pcons):
3026 W
Apparent Power Output:
170 kV·A
Efficiency Level:
IE2
Standby Loss:
52 W
