Long Description:
The ACS880-01 drives are customized to meet the particular needs of specific industries, such as oil and gas, mining, metals, chemicals, cement, power plants, material handling, pulp and paper, sawmills, marine, water and wastewater, food and beverage, and automotive. They can control a wide range of applications, including cranes, extruders, winches, winders, conveyors, mixers, compressors, centrifuges, test benches, elevators, extruders, pumps and fans. The ACS880-01 comes in one compact package for easy installation and commissioning. The drive can be installed on the wall as standard and in a cabinet as an option. The drive offering includes enclosure classes up to IP55, making it suitable for most environments and installations. ACS880-01 drives have all the essential features built-in. These features include as standard a choke for harmonic filtering as well as options like a brake chopper, EMC filter and communication protocol adapter, functional safety, external output filters and I/O extension modules.
Ordering
Customs Tariff Number:
85044085
HS Code:
850440 — ELECTRICAL MACHINERY AND EQUIPMENT AND PARTS THEREOF; SOUND RECORDERS AND REPRODUCERS, TELEVISION IMAGE AND SOUND RECORDERS AND REPRODUCERS, AND PARTS AND ACCESSORIES OF SUCH ARTICLES;Electrical transformers, static converters (for example, rectifiers) and inductors;Static converters
Invoice Description:
ACS880-01-045A-3 PN: 22 kW, IN: 45 A
Made To Order:
Yes
Minimum Order Quantity:
1 piece
Order Multiple:
1 piece
Quote Only:
No
Selling Unit of Measure:
piece
Dimensions
Product Net Weight:
18.6 kg
41.006 lb
Product Net Depth / Length:
274 mm
10.787 in
Product Net Height:
580 mm
22.835 in
Product Net Width:
203 mm
7.992 in
Package Level 1 Depth / Length:
691 mm
27.205 in
Package Level 1 Height:
329 mm
12.953 in
Package Level 1 Width:
290 mm
11.417 in
Package Level 1 Units:
1 carton
Certificates and Declarations
Declaration of Conformity – CE:
3AXD10000497831
REACH Date:
20250320
REACH Declaration:
9AKK107992A7060
REACH Information:
True – contains substances > 0.1 mass percentage
RoHS Date:
20240508
RoHS Information:
3AXD10000497831
RoHS Status:
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Technical
Number of Phases:
3-phase
Degree of Protection:
IP21
Enclosure Type NEMA:
Type1
Altitude:
4000 m
Operating Humidity (RHamb):
5 … 95
Sound dB (A):
64 dB(A)
Multiple Battery Information:
Lithium Coin, CR2032, 220 mAh, 3 V, 2 pcs, 6 g
Frequency (f):
47.5 … 63 Hz
Frame Size:
R4
Input Voltage (Uin):
380 … 415 V
Mounting Type:
Wall-mounted
Communication Protocol:
CAN
DeviceNet
EtherNet/IP
MODBUS
Other Bus Systems
PROFIsafe
PROFIBUS
PROFINET IO
Number of Hardware Interfaces:
Industrial Ethernet 0
Other 4
Parallel 0
PROFINET 0
RS-232 0
RS-422 0
RS-485 1
Serial TTY 0
USB 1
Includes:
Control unit
PC connection
Analog Inputs:
2
Analog Outputs:
2
Number of Digital In/Outputs:
6 / 2
Output Current, Normal Use (In):
45 A
Output Current, Light-Overload Use (ILD):
43 A
Output Current, Heavy-Duty Use (IHD):
38 A
Output Power, Normal Use (Pn):
22 kW
Output Power, Light-Overload Use (PLD):
22 kW
Output Power, Heavy-Duty Use (PHD):
18.5 kW
Power Consumption (@Pcons):
526 W
Apparent Power Output:
31 kV·A
Efficiency Level:
IE2
Standby Loss:
28 W
